Technical Specifications
Phase :
3 P
Resistive Load (AC-3) :
32 A
Inductive Load (AC-1) :
40 A
Auxiliary Contact Composition :
1N/O + 1N/C
Control Circuit Voltage :
220 VAC
Range OF Product :
C Series
Product OR Component Type :
Power Contactor
Utilisation Category :
AC-3, AC-4
[UE] Rated Operational Voltage :
Power Circuit: <= 690 V AC 50/60 HZ
[IE] Rated Operational Current :
32 A (AC-3) AT UE = 380/400 V, 50/60 HZ (Power Circuit)
Motor Power (KW) :
4 KW AT 380/400 V AC (AC-3), 50/60 HZ
Motor Power (HP) :
5.5 HP AT 380/400 V AC (AC-3), 50/60 HZ
Pole Contact Composition :
3 NO Main Contacts
[Ith] Conventional Free Air Thermal Current :
25 A
Rated Breaking Capacity :
According TO Utilisation Category AC-3 / AC-4 (IEC 60947- 4-1)
[UI] Rated Insulation Voltage :
Power Circuit: 690 V Conforming TO IEC 60947-4-1
[Uimp] Rated Impulse Withstand Voltage :
6 KV Conforming TO IEC 60947
Mechanical Durability :
10,000,000 Mcycles Operations
Electrical Durability :
1,000,000 Mcycles Operations (AC-3)
Control Circuit Type :
AC
Coil Technology :
AC Electromagnetic Coil
Control Circuit Voltage Limits :
Pick-UP: 85% – 110% US Drop-Out: 20% – 75% US
Inrush Power IN VA :
3600 VA
Hold-IN Power Consumption IN VA :
360 VA
Auxiliary Contact Composition :
1 NO + 1 NC Auxiliary Contacts (Standard)
Auxiliary Contacts Type :
Instantaneous
Mounting Support :
Screw Mounting 35 MM DIN Rail
Standards :
IEC / EN 60947-4-1
IP Degree Protection :
IP20 Front Face Conforming TO IEC 60529
Height :
8,3 CM
Width :
5,65 CM
Depth :
9,7 CM
Net Weight :
490,6 G
Warranty (IN Months) :
12
